Flickering checker-board using amdgpu laptop with external display and marco

jonathon · August 15, 2020, 2:40pm

I’ve tried to find a cause for this but failed so far.

I have an external monitor connected via an HDMI->DVI cable. It works correctly at resolutions lower than its maximum, and at maximum resolution when in a vertical orientation, and when placed “above” or “below” the laptop output (diagrams below). However, when placed to the “left” or “right” of the laptop output both displays end up with a flickering checker-board pattern, e.g.:

(The top “slice” of the screens display correctly)

It’s not a “new” issue, I’ve been putting up with it for a while by running the external display at a lower resolution.

I have tried setting “high” manually as per https://wiki.archlinux.org/index.php/AMDGPU#Screen_artifacts_and_frequency_problem , same end result.

I have tried a different cable.

The monitor and cable works correctly on another laptop (running nvidia).

There is no BIOS update for the system, different kernels give the same result, everything is current with Arch as of 2020-08-14T23:00:00Z.

It feels like this is a limitation on the horizontal resolution or virtual screen size:

Doesn’t work:

Works:

Doesn’t work:

Works:

So - yeah. Any ideas?

inxi -Fxxxz --no-host

System:    Kernel: 5.8.1-zen1-1-zen x86_64 bits: 64 compiler: N/A Desktop: MATE 1.24.1 info: mate-panel wm: marco 1.24.1
           dm: LightDM 1.30.0 Distro: Arch Linux
Machine:   Type: Laptop System: ASUSTeK product: GL702ZC v: 1.0 serial: <filter>
           Mobo: ASUSTeK model: GL702ZC v: 1.0 serial: <filter> UEFI: American Megatrends v: GL702ZC.306 date: 07/05/2019
Battery:   ID-1: BAT0 charge: 9.3 Wh condition: 9.3/74.2 Wh (13%) volts: 15.4/15.4 model: ASUSTeK ASUS Battery type: Li-ion
           serial: N/A status: Not charging cycles: 8
CPU:       Topology: 8-Core model: AMD Ryzen 7 1700 bits: 64 type: MT MCP arch: Zen rev: 1 L2 cache: 4096 KiB
           flags: avx avx2 lm nx pae sse sse2 sse3 sse4_1 sse4_2 sse4a ssse3 svm bogomips: 95804
           Speed: 1365 MHz min/max: 1550/3000 MHz boost: enabled Core speeds (MHz): 1: 1354 2: 1328 3: 1374 4: 1371 5: 1374
           6: 1375 7: 1374 8: 1374 9: 1548 10: 2105 11: 1332 12: 1332 13: 1339 14: 1328 15: 1374 16: 1374
Graphics:  Device-1: Advanced Micro Devices [AMD/ATI] Ellesmere [Radeon RX 470/480/570/570X/580/580X/590] vendor: ASUSTeK
           driver: amdgpu v: kernel bus ID: 0c:00.0 chip ID: 1002:67df
           Device-2: Realtek USB2.0 HD UVC WebCam type: USB driver: uvcvideo bus ID: 1-8:2 chip ID: 0bda:57fa serial: <filter>
           Display: x11 server: X.org 1.20.8 compositor: marco v: 1.24.1 driver: amdgpu resolution: <xdpyinfo missing>
           Message: Unable to show advanced data. Required tool glxinfo missing.
Audio:     Device-1: AMD Ellesmere HDMI Audio [Radeon RX 470/480 / 570/580/590] vendor: ASUSTeK driver: snd_hda_intel
           v: kernel bus ID: 0c:00.1 chip ID: 1002:aaf0
           Device-2: Advanced Micro Devices [AMD] Family 17h HD Audio vendor: ASUSTeK driver: snd_hda_intel v: kernel
           bus ID: 12:00.3 chip ID: 1022:1457
           Device-3: GYROCOM C&C Fiio E10 type: USB driver: hid-generic,snd-usb-audio,usbhid bus ID: 3-1.4:6
           chip ID: 1852:7022
           Sound Server: ALSA v: k5.8.1-zen1-1-zen
Network:   Device-1: Realtek RTL8111/8168/8411 PCI Express Gigabit Ethernet vendor: ASUSTeK driver: r8169 v: kernel port: e000
           bus ID: 06:00.0 chip ID: 10ec:8168
           IF: enp6s0 state: up speed: 1000 Mbps duplex: full mac: <filter>
           Device-2: Realtek RTL8822BE 802.11a/b/g/n/ac WiFi adapter vendor: AzureWave driver: rtw_8822be v: N/A port: d000
           bus ID: 07:00.0 chip ID: 10ec:b822
           IF: wlp7s0 state: down mac: <filter>
Drives:    Local Storage: total: 1.14 TiB used: 434.75 GiB (37.2%)
           ID-1: /dev/sda vendor: Seagate model: ST1000LM049-2GH172 size: 931.51 GiB speed: 6.0 Gb/s rotation: 7200 rpm
           serial: <filter> rev: SDM1 scheme: GPT
           ID-2: /dev/sdb vendor: SanDisk model: SD8SN8U256G1002 size: 238.47 GiB speed: 6.0 Gb/s serial: <filter> rev: 1002
           scheme: GPT
RAID:      Device-1: tank type: zfs status: ONLINE raid: no-raid size: 888.00 GiB free: 487.00 GiB allocated: 401.00 GiB
           Components: online: N/A
Partition: ID-1: / size: 40.00 GiB used: 12.16 GiB (30.4%) fs: btrfs dev: /dev/sdb4
           ID-2: /boot size: 975.9 MiB used: 334.4 MiB (34.3%) fs: ext4 dev: /dev/sdb2
           ID-3: /home size: 459.89 GiB used: 1.04 GiB (0.2%) fs: zfs raid: tank/home
Swap:      ID-1: swap-1 type: partition size: 40.00 GiB used: 0 KiB (0.0%) priority: -2 dev: /dev/sda1
Sensors:   System Temperatures: cpu: 62.5 C mobo: N/A gpu: amdgpu temp: 63 C
           Fan Speeds (RPM): N/A
Info:      Processes: 500 Uptime: 41m Memory: 31.30 GiB used: 5.82 GiB (18.6%) Init: systemd v: 246 Compilers: gcc: 10.1.0
           clang: 10.0.1 Packages: pacman: 1832 Shell: Zsh v: 5.8 running in: terminator inxi: 3.1.05

anon43355446 · August 15, 2020, 2:47pm

I’m having a similar artefact on both my external displays (hdmi and mini display port), but the pieces of the “board” are black and white and create a horizontal stripe. It appears occasionally for a very short time. Sometime I don’t see it all the evening, sometimes twice a minute. On 5.7.6 kernel it would appear very often. On 5.8.x the issue is bearable, but still present.

[edit] Different appearance may be caused by the fact, that 99% of the time I use sway/Wayland.

joekamprad · August 15, 2020, 3:21pm

Running xvidtune on the AMDgpu system shows the exact same current modeline. Only this time the screen flickers constantly and just the top ~13% of the screen is somewhat visible, every line below is unstable, interlaced, corrupted.

from: https://bugs.freedesktop.org/show_bug.cgi?id=96868
reads like exactly your issue

jonathon · August 15, 2020, 3:26pm

It also looks like it might be a marco issue:

Disabling marco’s software compositing-manager fixes the display issue, and running with picom doesn’t reintroduce the issue.

jonathon · August 15, 2020, 3:37pm

OK, I switched to metacity and the issue has “fixed” itself, so this is a marco bug.

metacity itself works fine and is nice and snappy, but wow is window resizing laggy.

keybreak · August 15, 2020, 4:01pm

Yeah, resizing is not metacity finest point, as i remember from Deepin 15.8 as well

jonathon · August 15, 2020, 4:09pm

Heh, I was just looking at that bug report…

jonathon · August 19, 2020, 1:56pm

After trying a few different options, I eventually configured picom --experimental-backends correctly and it’s now far snappier than marco was before with its software compositing (no compositing is still the most responsive option, but lack of shadows and transparency is a step too far for me for normal use). Even things like scrolling the forum in Firefox is more responsive.

picom.conf

backend = "glx";
use-damage = true;
glx-no-stencil = true;
glx-copy-from-front = false;
# glx-use-copysubbuffermesa = true;
# glx-no-rebind-pixmap = true;
#glx-swap-method = "undefined";
shadow = true;
shadow-radius = 20;
shadow-offset-x = -20;
shadow-offset-y = -18;
shadow-opacity = 0.3;
# shadow-red = 0.0;
# shadow-green = 0.0;
# shadow-blue = 0.0;
shadow-exclude = [
    "! name~=''",
    "name = 'Notification'",
    "name = 'Plank'",
    "name = 'Docky'",
    "name = 'Kupfer'",
    "name = 'xfce4-notifyd'",
    "name = 'cpt_frame_window'",
    "name *= 'VLC'",
    "name *= 'compton'",
    "name *= 'picom'",
    "name *= 'Chromium'",
    "name *= 'Chrome'",
    "class_g = 'Firefox' && window_type = 'utility'",
    "class_g = 'FirefoxNightly' && window_type = 'utility'",
    "class_g = 'Nightly' && window_type = 'utility'",
    "class_g = 'Tor Browser' && window_type = 'utility'",
    "class_g = 'TelegramDesktop' && argb",
    "class_g = 'Conky'",
    "class_g = 'Kupfer'",
    "class_g = 'Synapse'",
    "class_g ?= 'Notify-osd'",
    "class_g ?= 'Cairo-dock'",
    "class_g ?= 'Xfce4-notifyd'",
    "class_g ?= 'Xfce4-power-manager'",
    "_GTK_FRAME_EXTENTS@:c",
    "_NET_WM_STATE@:32a *= '_NET_WM_STATE_HIDDEN'"
];
shadow-ignore-shaped = false;
nactive-opacity = 1;
active-opacity = 1;
frame-opacity = 1;
inactive-opacity-override = false;
# inactive-dim = 0.2;
blur: {
    method = "box";
    strength = 10;
}
blur-background = true;
# blur-kern = "3x3box";
# blur-background-frame = true;
blur-background-fixed = false;
blur-background-exclude = [
    "window_type = 'dock'",
    "window_type = 'desktop'"
];
fading = false;
fade-delta = 4;
fade-in-step = 0.03;
fade-out-step = 0.03;
no-fading-openclose = true;
fade-exclude = [ ];

mark-wmwin-focused = true;
mark-ovredir-focused = true;
#use-ewmh-active-win = true;
detect-rounded-corners = true;
detect-client-opacity = true;
refresh-rate = 0;
vsync = false;
dbe = false;
unredir-if-possible = false;
focus-exclude = [ "class_g = 'Cairo-clock'" ];
detect-transient = true;
detect-client-leader = true;
wintypes:
{
    tooltip =
    {
        # fade: Fade the particular type of windows.
        fade = true;
        # shadow: Give those windows shadow
        shadow = false;
        # opacity: Default opacity for the type of windows.
        opacity = 0.85;
        # focus: Whether to always consider windows of this type focused.
        focus = true;
    };
};
xrender-sync-fence = true;

Hopefully the bug will be fixed at some point, but it needs some input on what’s needed and where to start with debugging.
