How to open firewalld ports correctly?

General system Newbie
1

Hello,

I have a problem to open ports with firewalld, which should be easy according to all the guides and comments I read. I want to set up a NFS server between my PC and Laptop in my home network. According to Arch Wiki I installed nfs-utils and opened the ports 2049, 111 TCP & UDP, added folder and IP to exports.

I checked the server from my client with rpc, which returns a port list. Then I want to check the server provided folder with showmount -e IPAdress, which gives me

rpc mount export: RPC: Unable to receive; errno = No route to host

Changing the zone to trusted, solves the problem as usual, like all the other things I tried lately.

I want to understand firewalld, but the guides and documentation does not provide me the information to solve the problem or where the issue is coming from. Why are the ports I open not open? Is there another firewall layer? Why is firewalld so much more in the way then ufw? What am I doing wrong, and why is no guide mentioning anything of the extra steps to make it work?

2

How did you open them?

A few recommendations:

  • Make sure you aren’t using the KDE firewall management kcm but the actual firewalld GUI.
  • Don’t try to open indivual ports, just enable the nfs and rpc-bind services for the correct zone.
  • Make sure you consider both the runtime configuration and the permanent configuration
3

Thank you for your reply.

There was a firewall window under the system settings, so I removed the plasma-firewall.

I opened the ports via the “Firewall Configuration” GUI. I also checked the nfs and rpc-bind service in runtime and permanent. Rebooted the Laptop

The result, no change with showmount -e. If I switch to trusted, everything works as expected.

image970Ă—682 86.7 KB

1 Like
4

I removed plasma-firewall and firewalld, everything that was inside the /etc/firwalld folder, rebooted the system. Then reinstalled firewalld, checked the nfs and rpc services, but no change. I can’t acces the nfs folder from another PC without setting firewalld to “trusted”.

I guess as @dalto said it is related to plasma-firewall, which I guess is somewhere, after being removing still having a config file which is getting in the way of my firewalld configuration.

Why is plasma-firewall still in the plasma collection when it is causing problems, I guess I am not the only one?

5

Have you tried the home zone? I’ve been using that for a few years now, works great on my home/VM network. One thing that I also do with NFS (version 4) is use insecure ports, like this:

# /etc/exports
/my_share   192.168.122.0/24(rw,sync,insecure,no_subtree_check,crossmnt,fsid=0)

sudo exportfs -arv
sudo systemctl enable --now nfsv4-server.service

For setting the firewall:

sudo firewall-cmd --set-default-zone home
sudo firewall-cmd --permanent --zone=home --add-service=nfs
sudo firewall-cmd --complete-reload
6

/etc/exports

/my_share   192.168.122.0/24(rw,sync,insecure,no_subtree_check,crossmnt,fsid=0)

sudo exportfs -arv
sudo systemctl enable --now nfsv4-server.service

I tried this instead of only rw and sync but no change.

I made the change to home and selected it for the local network, but no change. My home zone config:

image311Ă—345 30.9 KB

I googled a few hours about the plasma-firewall and firewalld, there seems to be a conflict, but also not really a solution and also not really a documentation about plasma-firewall or I have just missed it.

7

I think I remember running into this when I tried KDE, but I’ve since moved back to Xfce. I wish you luck.

1 Like
8

Thank you, I am also thinking about switching to something else, I encountered to many conflicts with KDE, but I had no time to explore different DEs with wayland support for gaming or combine them myself.

9

that’s strange that the default firewall and the DE firewall are not working in harmony and against its user but that makes a perverted amt of sense since only one firewall can be El Capitan..

And your research said this was a known known (as it were)?

I’ve never run KDE so I have no idea how this works..you removed the KDE firewall and still can’t open ports?

Spitballing:

  1. coming from dirt-simple UFW to FirewallD it’s way way over my head. Maybe some youtube tutorials would help? Firewalld the D is for daunting :). I remember not even being able to rip the bonjour stuff out it it once (again, my own ineptness).

  2. I am too accident-prone for this, but I wonder if it could be solved (ports opened) thru IP tables?

10

I found serval entries in different linux forums. There are also hints that ufw and plasma-firewall should work.

Another night. I read the firewalld documentation and removed firewalld and removed all it’s associated config folders, which i found here:

I reinstalled firewalld, edited a new home-zone and checked if the services are listed and the home is the active zone, which is the case:

$ firewall-cmd --zone=home --list-all
home (active)
target: default
ingress-priority: 0
egress-priority: 0
icmp-block-inversion: no
interfaces: lo wlan0
sources:
services: dhcpv6-client mdns nfs nfs3 rpc-bind samba-client ssh
ports:
protocols:
forward: yes
masquerade: no
forward-ports:
source-ports:
icmp-blocks:
rich rules:

As usual no changes, i still can’t access nfs without the “trusted” zone. If i find time in the next days, i am going to remove firewalld and try ufw. The firewalld gui seemed so simple.

11

On the NFS server, you’d most probably need to open a lot more for it to work. NFS uses a lot of ports when doing stuff with a server, and besides, we have NFSv2, v3, v4. NFSv4 is the most modern (and secure) and has many of the extras built-in (so less ports to open), but most Linuxes nowadays still default to NFSv3, which at least needs rpcbind, mountd, lockd, and statd to function.

Baeldung have a nice write-up for firewalld here:

https://www.baeldung.com/linux/firewalld-nfs-connections-settings

I’d go for creating a new named rule set (maybe “nfs-server” or the like), and put the settings in there. Then you can later select the runtime or permanent setting for any desired zone and just put a checkmark next to “nfs-server”. I use this mechanism for Calibre, as an example.

12

Firewalld already ships with the services you need for NFS pre-defined, you don’t need to create your own in this case.

13

For a server, too? Not just for clients? (That would be nice!) The OP wants to run an NFS server as far as I remember.

14

Yes. For the server. You shouldn’t need to open ports for the clients.

15

Hm. nfs only opens 2049/tcp, that would surely not be enough for NFSv3, maybe for NFSv4…

nfs3 only opens 2049/tcp and 2049/udp.

With only this setup, mount, showmount, lock and stat would surely fail, I think.

16

I guess the question becomes, “Is the OP using NFS v4 or v3?” One would hope a new setup in 2025 would be using v4.

17

Well, that’d be one good question. I’d guess, though, that the majority of Linuxes (incl. Arch/EOS) still default to NFSv3.

An easy test from a client pc to the server pc could be:

$ showmount -e serverpc

If it gets stuck or shows RPC errors, more is needed. :wink:
Otherwise, it should show the mountable NFS exports of the server pc.

NFS ain’t the easiest to set up (I fiddled long for my NAS stuff), but once it’s set up it’s really great.

18

According to the guides i read i need the port 2049 tcp for nfs4, but for rpcbind and showmount -e i would need 2049 tcp/ upd and 111 tcp/udp. Which should be enabled by checking the services in firewalld. I also tried to open the ports via the port tab in the firewalld gui.

Most infos i got from the arch wiki:

19

There might be more. mountd might add 20048, rdma might add 20049, and so forth.

You might be able to find some of these (and setup options) in /etc/nfs.conf.

And don’t miss this:

By default, rpc.mountd selects a port dynamically, so if you’re behind a firewall you will want to edit /etc/nfs.conf to set a static port instead. Use rpcinfo -p to examine the exact ports in use on the NFSv3 server.

If you don’t set a fixed port, it will use random tcp ports, and surely fail. A fixed port can be put into the firewalld config.

20

rpcinfo -p shows these ports and services.

program vers proto port service
100000 4 tcp 111 portmapper
100000 3 tcp 111 portmapper
100000 2 tcp 111 portmapper
100000 4 udp 111 portmapper
100000 3 udp 111 portmapper
100000 2 udp 111 portmapper
100003 4 tcp 2049 nfs
100024 1 udp 44420 status
100005 1 udp 20048 mountd
100024 1 tcp 59587 status
100005 1 tcp 20048 mountd
100005 2 udp 20048 mountd
100005 2 tcp 20048 mountd
100005 3 udp 20048 mountd
100005 3 tcp 20048 mountd
