Help needed - 144Hz setup with Plasma, Wayland, Nvidia

General system Kernel, boot, graphics & hardware
1

Hello.
I’m trying to make my main monitor work in 144Hz, but whenever I set it to that rate in display settings, it just goes black. Here’s my setup:

  • KDE Plasma 6.2.3, Wayland
  • NVIDIA GeForce RTX 3080, nvidia-utils 565.57.01-1
  • Acer Nitro VG240Y S, HDMI connection
  • Samsung syncMaster BX2235, VGA->DP connection

Like previously mentioned, I want my Acer monitor to work in 144Hz, but can’t figure out why it’s going black.
One possible clue I discovered, was that my nvidia-settings doesn’t really show any information. Although I’m not too sure what to make of it.

image1006×785 104 KB

Any help will be much appreciated.

2

nvidia-settings only works properly under X11. Under Wayland it only shows what you are seeing on your screenshot. This not a bug / problem.

Did you try disabling Freesync in the settings of the monitor (not the Plasma settings) yet?

3

Hi, thanks for the answer.
I tried it just now, but it did not seem to change much. One additional thing I found out, was that the monitor works fine with 120Hz.
Do you think it might be related to the HDMI connection? I read somewhere that DisplayPort is needed for 144Hz on Linux, but I find it hard to believe.

4

No support for HDMI 2.1 (and thus high refresh rates combined with high resolutions) is only an issue with AMD GPUs on Linux. They are currently not allowed to implement it in their open source driver.

Nvidia should work fine over HDMI.

I had a quick look at the specs of the monitor and it lists support for 144Hz for both HDMI and DisplayPort. Some Monitors have restrictions there. They don’t list the HDMI version tho.

Regardless you should try with DisplayPort and see if it behaves the same.

1 Like
5

What are the results?
I am experiencing the same issue and I plan to buy a DisplayPort cable.

6

Hello, sorry for the late reply, I don’t check the forum often :sweat_smile:

I decided to just buy a DisplayPort cable (one that I made sure can handle a FullHD 144Hz display) and that actually fixed it. I’ve been using it ever since and haven’t run into any trouble.

I’m not sure if I should mark this as the solution though, because it doesn’t really solve the issue with HDMI

1 Like
7

I had a similar issue a while back with a 165Hz monitor. Display port gives full Hz functionality. HDMI is limited.

HDMI and DisplayPort are both digital video interfaces used to connect devices like computers and monitors. While both can transmit audio and video, DisplayPort generally offers higher bandwidth, allowing for higher resolutions and refresh rates, while HDMI is more prevalent on TVs and gaming consoles.
