GPU Passthrough Sucessful, But VM is Not Using GPU

General system Newbie
1

I recently got GPU passthrough working through Virt-Manager and QEMU.
Successfully installed a Windows 10 VM, it recognizes the GPU and I’m able to update the drivers properly.

What I found strange is that when checking DxDiag there’s only a listing for the Red Hat VirtIO driver

image963×562 136 KB

When I try to launch Photoshop CS6 and check the performance preferences it doesn’t seem to recognize my GPU either.

I’ve used UserBenchmark to test the system and it seems to recognize my passthrough GPU either.

To be frank, I’m not sure what troubleshooting steps to take to resolve this.

1 Like
2

Looks like Windows. :scream:

2 Likes
3

I’m sorry, I’ve blasphemed :sob:

4

Did you ever delete the vGPU from the VM?

5

I assume you might the referring to the virtual hardware details menu? Where it lists Overview, OS information, Performance etc.

The devices that I have listed that refer to display are Video Virtio, PCI devices for the GPU passthrough, Channel (spice), Display Spice. Which of those is the vGPU?

6

You’ll need to get rid of the Video VirtIO and anything related to Spice. I use evdev to share my mouse and keyboard so I don’t need Spice at all. For reference, here is my windows-10.xml:

(Sorry - tried to post a link generated with eos-sendlog, but it came out scrambled)

<!--
WARNING: THIS IS AN AUTO-GENERATED FILE. CHANGES TO IT ARE LIKELY TO BE
OVERWRITTEN AND LOST. Changes to this xml configuration should be made using:
  virsh edit windows-10
or other application using the libvirt API.
-->

<domain type='kvm' xmlns:qemu='http://libvirt.org/schemas/domain/qemu/1.0'>
  <name>windows-10</name>
  <uuid>064278e2-1ff2-4dbc-b524-94da12037cca</uuid>
  <title>Windows 10 (Home w/GPU &amp; disk pass-through)</title>
  <description>My gaming machine</description>
  <metadata>
    <libosinfo:libosinfo xmlns:libosinfo="http://libosinfo.org/xmlns/libvirt/domain/1.0">
      <libosinfo:os id="http://microsoft.com/win/10"/>
    </libosinfo:libosinfo>
  </metadata>
  <memory unit='KiB'>16777216</memory>
  <currentMemory unit='KiB'>16777216</currentMemory>
  <memoryBacking>
    <source type='memfd'/>
    <access mode='shared'/>
  </memoryBacking>
  <vcpu placement='static'>8</vcpu>
  <iothreads>2</iothreads>
  <cputune>
    <vcpupin vcpu='0' cpuset='8'/>
    <vcpupin vcpu='1' cpuset='9'/>
    <vcpupin vcpu='2' cpuset='10'/>
    <vcpupin vcpu='3' cpuset='11'/>
    <vcpupin vcpu='4' cpuset='12'/>
    <vcpupin vcpu='5' cpuset='13'/>
    <vcpupin vcpu='6' cpuset='14'/>
    <vcpupin vcpu='7' cpuset='15'/>
    <emulatorpin cpuset='0-1'/>
    <iothreadpin iothread='1' cpuset='0-1'/>
    <iothreadpin iothread='2' cpuset='2-3'/>
  </cputune>
  <os firmware='efi'>
    <type arch='x86_64' machine='pc-q35-7.1'>hvm</type>
    <nvram>/var/lib/libvirt/qemu/nvram/windows-10_VARS.fd</nvram>
    <bootmenu enable='yes'/>
  </os>
  <features>
    <acpi/>
    <apic/>
    <hyperv mode='custom'>
      <relaxed state='on'/>
      <vapic state='on'/>
      <spinlocks state='on' retries='8191'/>
      <vpindex state='on'/>
      <runtime state='on'/>
      <synic state='on'/>
      <reset state='on'/>
    </hyperv>
    <kvm>
      <hidden state='on'/>
    </kvm>
    <vmport state='off'/>
  </features>
  <cpu mode='host-passthrough' check='none' migratable='on'>
    <topology sockets='1' dies='1' cores='4' threads='2'/>
    <cache mode='passthrough'/>
    <feature policy='disable' name='vmx'/>
    <feature policy='disable' name='hypervisor'/>
    <feature policy='require' name='topoext'/>
  </cpu>
  <clock offset='localtime'>
    <timer name='rtc' tickpolicy='catchup'/>
    <timer name='pit' tickpolicy='delay'/>
    <timer name='hpet' present='no'/>
    <timer name='hypervclock' present='yes'/>
  </clock>
  <on_poweroff>destroy</on_poweroff>
  <on_reboot>restart</on_reboot>
  <on_crash>destroy</on_crash>
  <pm>
    <suspend-to-mem enabled='no'/>
    <suspend-to-disk enabled='no'/>
  </pm>
  <devices>
    <emulator>/usr/bin/qemu-system-x86_64</emulator>
    <disk type='block' device='disk'>
      <driver name='qemu' type='raw' cache='none' io='threads' discard='unmap'/>
      <source dev='/dev/disk/by-id/ata-SanDisk_SDSSDH3512G_185274805963'/>
      <target dev='sda' bus='scsi'/>
      <boot order='1'/>
      <address type='drive' controller='0' bus='0' target='0' unit='0'/>
    </disk>
    <disk type='file' device='cdrom'>
      <driver name='qemu' type='raw'/>
      <target dev='sdb' bus='sata'/>
      <readonly/>
      <boot order='2'/>
      <address type='drive' controller='0' bus='0' target='0' unit='1'/>
    </disk>
    <disk type='file' device='cdrom'>
      <driver name='qemu' type='raw'/>
      <source file='/var/lib/libvirt/images/virtio-win.iso'/>
      <target dev='sdc' bus='sata'/>
      <readonly/>
      <address type='drive' controller='0' bus='0' target='0' unit='2'/>
    </disk>
    <controller type='usb' index='0' model='qemu-xhci' ports='15'>
      <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/>
    </controller>
    <controller type='pci' index='0' model='pcie-root'/>
    <controller type='pci' index='1' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='1' port='0x10'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0' multifunction='on'/>
    </controller>
    <controller type='pci' index='2' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='2' port='0x11'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x1'/>
    </controller>
    <controller type='pci' index='3' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='3' port='0x12'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x2'/>
    </controller>
    <controller type='pci' index='4' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='4' port='0x13'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x3'/>
    </controller>
    <controller type='pci' index='5' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='5' port='0x14'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x4'/>
    </controller>
    <controller type='pci' index='6' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='6' port='0x15'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x5'/>
    </controller>
    <controller type='pci' index='7' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='7' port='0x16'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x6'/>
    </controller>
    <controller type='pci' index='8' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='8' port='0x17'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x7'/>
    </controller>
    <controller type='pci' index='9' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='9' port='0x18'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0' multifunction='on'/>
    </controller>
    <controller type='pci' index='10' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='10' port='0x19'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x1'/>
    </controller>
    <controller type='pci' index='11' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='11' port='0x1a'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x2'/>
    </controller>
    <controller type='pci' index='12' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='12' port='0x1b'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x3'/>
    </controller>
    <controller type='pci' index='13' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='13' port='0x1c'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x4'/>
    </controller>
    <controller type='pci' index='14' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='14' port='0x1d'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x5'/>
    </controller>
    <controller type='pci' index='15' model='pcie-root-port'>
      <model name='pcie-root-port'/>
      <target chassis='15' port='0x1e'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x6'/>
    </controller>
    <controller type='pci' index='16' model='pcie-to-pci-bridge'>
      <model name='pcie-pci-bridge'/>
      <address type='pci' domain='0x0000' bus='0x05' slot='0x00' function='0x0'/>
    </controller>
    <controller type='sata' index='0'>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/>
    </controller>
    <controller type='virtio-serial' index='0'>
      <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/>
    </controller>
    <controller type='scsi' index='0' model='virtio-scsi'>
      <driver queues='8'/>
      <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0'/>
    </controller>
    <interface type='network'>
      <mac address='52:54:00:53:80:f8'/>
      <source network='default'/>
      <model type='virtio'/>
      <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/>
    </interface>
    <serial type='pty'>
      <target type='isa-serial' port='0'>
        <model name='isa-serial'/>
      </target>
    </serial>
    <console type='pty'>
      <target type='serial' port='0'/>
    </console>
    <input type='evdev'>
      <source dev='/dev/input/by-id/usb-30fa_USB_OPTICAL_MOUSE-event-mouse'/>
    </input>
    <input type='evdev'>
      <source dev='/dev/input/by-id/usb-SEMICO_USB_Keyboard-event-if01' grab='all' repeat='on'/>
    </input>
    <input type='evdev'>
      <source dev='/dev/input/by-id/usb-SEMICO_USB_Keyboard-event-kbd' grab='all' grabToggle='ctrl-ctrl' repeat='on'/>
    </input>
    <input type='mouse' bus='ps2'/>
    <input type='keyboard' bus='ps2'/>
    <audio id='1' type='none'/>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <source>
        <address domain='0x0000' bus='0x0b' slot='0x00' function='0x3'/>
      </source>
      <address type='pci' domain='0x0000' bus='0x08' slot='0x00' function='0x0'/>
    </hostdev>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <source>
        <address domain='0x0000' bus='0x09' slot='0x00' function='0x0'/>
      </source>
      <address type='pci' domain='0x0000' bus='0x07' slot='0x00' function='0x0'/>
    </hostdev>
    <watchdog model='itco' action='reset'/>
    <memballoon model='virtio'>
      <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/>
    </memballoon>
  </devices>
  <qemu:override>
    <qemu:device alias='scsi0-0-0-0'>
      <qemu:frontend>
        <qemu:property name='rotation_rate' type='unsigned' value='1'/>
        <qemu:property name='discard_granularity' type='unsigned' value='0'/>
      </qemu:frontend>
    </qemu:device>
  </qemu:override>
</domain>
7

I’ve cloned the machine I’m trying to get to work and removed the entries in the xml file for Video VirtIO and anything that related to Spice.
It boots into a terminal interface and a blinking cursor.

Perhaps posting what I have as my current working configuration will help.

<domain type="kvm">
  <name>Win10</name>
  <uuid>e8412db0-0078-48fb-ad2d-91ea155d519b</uuid>
  <metadata>
    <libosinfo:libosinfo xmlns:libosinfo="http://libosinfo.org/xmlns/libvirt/domain/1.0">
      <libosinfo:os id="http://microsoft.com/win/10"/>
    </libosinfo:libosinfo>
  </metadata>
  <memory unit="KiB">8388608</memory>
  <currentMemory unit="KiB">8388608</currentMemory>
  <vcpu placement="static">8</vcpu>
  <os firmware="efi">
    <type arch="x86_64" machine="pc-q35-7.2">hvm</type>
  </os>
  <features>
    <acpi/>
    <apic/>
    <hyperv mode="custom">
      <relaxed state="on"/>
      <vapic state="on"/>
      <spinlocks state="on" retries="8191"/>
    </hyperv>
    <vmport state="off"/>
  </features>
  <cpu mode="host-passthrough" check="none" migratable="on">
    <topology sockets="1" dies="1" cores="4" threads="2"/>
  </cpu>
  <clock offset="localtime">
    <timer name="rtc" tickpolicy="catchup"/>
    <timer name="pit" tickpolicy="delay"/>
    <timer name="hpet" present="no"/>
    <timer name="hypervclock" present="yes"/>
  </clock>
  <on_poweroff>destroy</on_poweroff>
  <on_reboot>restart</on_reboot>
  <on_crash>destroy</on_crash>
  <pm>
    <suspend-to-mem enabled="no"/>
    <suspend-to-disk enabled="no"/>
  </pm>
  <devices>
    <emulator>/usr/bin/qemu-system-x86_64</emulator>
    <disk type="file" device="disk">
      <driver name="qemu" type="qcow2"/>
      <source file="/mnt/e3ca5c9f-266d-4190-bf29-cb4cca23719e/VM Storage Pools/win10.qcow2"/>
      <target dev="sda" bus="sata"/>
      <boot order="1"/>
      <address type="drive" controller="0" bus="0" target="0" unit="0"/>
    </disk>
    <disk type="file" device="cdrom">
      <driver name="qemu" type="raw"/>
      <source file="/mnt/e3ca5c9f-266d-4190-bf29-cb4cca23719e/Downloads/OS ISOs/virtio-win-0.1.229.iso"/>
      <target dev="sdb" bus="sata"/>
      <readonly/>
      <address type="drive" controller="0" bus="0" target="0" unit="1"/>
    </disk>
    <controller type="usb" index="0" model="qemu-xhci" ports="15">
      <address type="pci" domain="0x0000" bus="0x02" slot="0x00" function="0x0"/>
    </controller>
    <controller type="pci" index="0" model="pcie-root"/>
    <controller type="pci" index="1" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="1" port="0x10"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x0" multifunction="on"/>
    </controller>
    <controller type="pci" index="2" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="2" port="0x11"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x1"/>
    </controller>
    <controller type="pci" index="3" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="3" port="0x12"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x2"/>
    </controller>
    <controller type="pci" index="4" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="4" port="0x13"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x3"/>
    </controller>
    <controller type="pci" index="5" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="5" port="0x14"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x4"/>
    </controller>
    <controller type="pci" index="6" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="6" port="0x15"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x5"/>
    </controller>
    <controller type="pci" index="7" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="7" port="0x16"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x6"/>
    </controller>
    <controller type="pci" index="8" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="8" port="0x17"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x7"/>
    </controller>
    <controller type="pci" index="9" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="9" port="0x18"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x03" function="0x0" multifunction="on"/>
    </controller>
    <controller type="pci" index="10" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="10" port="0x19"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x03" function="0x1"/>
    </controller>
    <controller type="pci" index="11" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="11" port="0x1a"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x03" function="0x2"/>
    </controller>
    <controller type="pci" index="12" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="12" port="0x1b"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x03" function="0x3"/>
    </controller>
    <controller type="pci" index="13" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="13" port="0x1c"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x03" function="0x4"/>
    </controller>
    <controller type="pci" index="14" model="pcie-root-port">
      <model name="pcie-root-port"/>
      <target chassis="14" port="0x1d"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x03" function="0x5"/>
    </controller>
    <controller type="sata" index="0">
      <address type="pci" domain="0x0000" bus="0x00" slot="0x1f" function="0x2"/>
    </controller>
    <controller type="virtio-serial" index="0">
      <address type="pci" domain="0x0000" bus="0x03" slot="0x00" function="0x0"/>
    </controller>
    <interface type="network">
      <mac address="52:54:00:2f:87:1b"/>
      <source network="default"/>
      <model type="e1000e"/>
      <address type="pci" domain="0x0000" bus="0x01" slot="0x00" function="0x0"/>
    </interface>
    <serial type="pty">
      <target type="isa-serial" port="0">
        <model name="isa-serial"/>
      </target>
    </serial>
    <console type="pty">
      <target type="serial" port="0"/>
    </console>
    <channel type="spicevmc">
      <target type="virtio" name="com.redhat.spice.0"/>
      <address type="virtio-serial" controller="0" bus="0" port="1"/>
    </channel>
    <input type="tablet" bus="usb">
      <address type="usb" bus="0" port="1"/>
    </input>
    <input type="mouse" bus="ps2"/>
    <input type="keyboard" bus="ps2"/>
    <input type="mouse" bus="usb">
      <address type="usb" bus="0" port="4"/>
    </input>
    <graphics type="spice">
      <listen type="none"/>
      <image compression="off"/>
      <gl enable="no"/>
    </graphics>
    <sound model="ich9">
      <address type="pci" domain="0x0000" bus="0x00" slot="0x1b" function="0x0"/>
    </sound>
    <audio id="1" type="spice"/>
    <video>
      <model type="virtio" heads="1" primary="yes"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x01" function="0x0"/>
    </video>
    <hostdev mode="subsystem" type="pci" managed="yes">
      <source>
        <address domain="0x0000" bus="0x02" slot="0x00" function="0x0"/>
      </source>
      <address type="pci" domain="0x0000" bus="0x04" slot="0x00" function="0x0"/>
    </hostdev>
    <hostdev mode="subsystem" type="pci" managed="yes">
      <source>
        <address domain="0x0000" bus="0x02" slot="0x00" function="0x1"/>
      </source>
      <address type="pci" domain="0x0000" bus="0x05" slot="0x00" function="0x0"/>
    </hostdev>
    <redirdev bus="usb" type="spicevmc">
      <address type="usb" bus="0" port="2"/>
    </redirdev>
    <redirdev bus="usb" type="spicevmc">
      <address type="usb" bus="0" port="3"/>
    </redirdev>
    <watchdog model="itco" action="reset"/>
    <memballoon model="virtio">
      <address type="pci" domain="0x0000" bus="0x06" slot="0x00" function="0x0"/>
    </memballoon>
  </devices>
</domain>
8

This is the part that is interfering with your passed-through GPU:

<video>
    <model type="virtio" heads="1" primary="yes"/>
    <address type="pci" domain="0x0000" bus="0x00" slot="0x01" function="0x0"/>
</video>

Here’s what my VM looks like in virt-manager:

Screenshot from 2023-03-24 21-41-01
Screenshot from 2023-03-24 21-41-01774×661 60.2 KB

9

Change the video string to “none” and you should be good to go. Also highly recommend you use evdev passthrough instead of spice.

10

I’ve attempted multiple times to remove the Video entry, but it keeps on regenerating with Video Cirrus.
When I set it to None and try to boot the machine, I’m stuck at a screen saying “Connecting to graphical console for guest”.

11

It’s probably because of the Spice connections, which mine doesn’t have. I’ll take a look more tomorrow.

12

Odd, I’ve attempted to remove those Spice connections and the Video VirtIO. The changes don’t seem to want to stick.

13

Try it from virsh.

14

I’ve tried editing them with sudo virsh, still no change.

15

Repent.

16

So you can ise GPU passthrough with single GPU and still have a normal linux DE session in background?
Last te I’ve read about it’s been saying that the gpu-passthrough requires a restart of the session to continue use Linux graphical interface.

17

Did not know that you’re trying this with a single GPU. Mine’s got a dedicated 2nd GPU that I only use for VMs. All I have to do is switch monitor inputs.

1 Like
18

I can say for sure I’ve got two GPUs installed on the host system. One has been dedicated to VMs.

19

Eh, understood. Thanks anyway.

20

I don’t think having a spice controller and video device is what the problem is. I have both in my machine along side my passed through gpu. I leave them attached for troubleshooting purposes. Sometimes I can only upgrade my gpu driver in my VM if I install via a qxl monitor. Because while installing the driver it will blank my hardware monitor and it won’t come back and I have to continue the install via the qxl/software monitor and reboot the machine.

Though it may be because the video model is using virtio

It certainly won’t hurt to remove them to help narrow down the issue. If it’s not staying deleted when you apply the changes it usually means something else relies on it. Try to delete the “hardware” from the virt-manager gui list, it will often tell you what the issue is or what’s preventing you from removing the device.

From what I see there are several related sections:

remove:

   <channel type="spicevmc">
      <target type="virtio" name="com.redhat.spice.0"/>
      <address type="virtio-serial" controller="0" bus="0" port="1"/>
    </channel>

remove:

    <graphics type="spice">
      <listen type="none"/>
      <image compression="off"/>
      <gl enable="no"/>
    </graphics>

change:

    <video>
      <model type="virtio" heads="1" primary="yes"/>
      <address type="pci" domain="0x0000" bus="0x00" slot="0x01" function="0x0"/>
    </video>

to:

    <video>
      <model type="none"/>
    </video>

remove:

    <redirdev bus="usb" type="spicevmc">
      <address type="usb" bus="0" port="2"/>
    </redirdev>
    <redirdev bus="usb" type="spicevmc">
      <address type="usb" bus="0" port="3"/>
    </redirdev>

change:

    <input type="mouse" bus="usb">
      <address type="usb" bus="0" port="4"/>
    </input>

to: (use ls -l /dev/input/by-id to find mouse and keyboard ID to replace appropriate spot.)

    <input type="evdev">
      <source dev="/dev/input/by-id/MOUSE_ID"/>
    </input>
    <input type="evdev">
      <source dev="/dev/input/by-id/KEYBOARD_ID" grab="all" repeat="on"/>
    </input>

(With evdev use LCTRL+RCTRL to swap mouse&keyboard between host&guest)

Unrelated:
@ajgringo619 What’s the point of setting those hyperv flags when you disable it? Typically disabling hypervisor reduces performance. Another potential performance killer is the shared mem, you should remove <source type='memfd'/> <access mode='shared'/> unless you have a specific reason for it.

@ajgringo619 and @Zer0sVoid I see you both have memballoon enabled, it’s another performance killer unless you have a specific reason for it you should turn it off <memballoon model='none'/>

@Zer0sVoid topoext is important for the guest to recognize hyperthreading you should specify it under the cpu mode with <feature policy='require' name='topoext'/> . You also need to change the namespace at the very top <domain xmlns:qemu="http://libvirt.org/schemas/domain/qemu/1.0" type="kvm">

Finally, you can get more assistance at the discord group: https://www.reddit.com/r/VFIO/comments/5b5znr/click_here_to_join_the_vfio_discord_server/

2 Likes
